CANAL PAVING MACHINE

Name: CANAL PAVING MACHINE
Brand: Indotex Equipments
Price: 1000000.00 INR
Availability: InStock

Price 1000000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

CANAL PAVING MACHINE Specification

Surface
Powder Coated

Lifting Speed
Variable (Depending on model and operation)

Lifting Height
Customizable as per site requirement

Motor Power
7.5 HP

Product Type
Canal Paving Machine

General Use
Construction of canal liners and irrigation channels

Material
Mild Steel / Stainless Steel (Sheet and Frame)

Type
Hydraulic and Mechanical

Capacity
Up to 500 Cubic Meter per Day

Weight (kg)
2500 - 3500 kg (Depending on configuration)

Computerized
No

Automatic
Yes

Control System
Manual and Semi-Automatic Controls

Cooling System
Air Cooled

Method
Concrete Lining and Pairing

Voltage
Three Phase, 415 V

Dimension (L*W*H)
Approx 5000 mm x 2500 mm x 2200 mm

Feature
Robust Construction, High Durability, Precise Lining

Color
Industrial Yellow / Blue / Custom

Operator Requirement
1-2 Operators

Vibration System
Integrated for Compaction

Drive Mechanism
Heavy Duty Gearbox and Chain Drive

Power Source
Electric / Diesel Engine (Optional)

Mobility
Fitted with Heavy Duty Wheels

Application
For irrigation canal construction and concrete lining operations

Working Width
Up to 3.5 meter

Maintenance
Low, Easy Access Service Points

Paving Thickness
80 mm to 300 mm adjustable

Travel Speed
0-10 m/min variable

Safety Features
Emergency Stop Switch, Overload Protection

Gradeability
Up to 5% slope operation

Finishing Mode
Trowel and Roller Type

Working Temperature Range
-10C to +50C

CANAL PAVING MACHINE Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA)

Supply Ability
10 Units Per Day

Delivery Time
10 Days

Sample Policy
Contact us for information regarding our sample policy

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About CANAL PAVING MACHINE

Why Choose Our Canal Paver?

Seamless Finish: Achieve a smooth, crack-resistant concrete lining that maximizes water flow and minimizes seepage.
Customizable Frames: Modular designs that adjust to varying canal widths, depths, and slope angles.
High Output: Engineered for continuous operation, reducing project timelines and labor costs.
Precision Control: Advanced hydraulic systems for pinpoint accuracy in thickness and grade control.

Advanced Design for Superior Canal Lining

Built for intense irrigation projects, the CANAL PAVING MACHINE ensures high durability and precision with its robust frame and advanced vibration compaction. Its heavy-duty drive mechanism and mobility wheels allow seamless material handling across challenging terrains, making it a reliable choice for contractors.

Versatile Performance and User-Friendly Operation

With adjustable paving thickness and customizable lifting height, this machine accommodates various site requirements. Featuring manual and semi-automatic control options, it achieves efficient output with just 1-2 operators. The integrated safety features safeguard the machine and its users during extended operations.

FAQ's of CANAL PAVING MACHINE:

Q: How does the CANAL PAVING MACHINE improve canal lining projects?

A: This machine streamlines the canal lining process by delivering consistent, high-quality finishes at adjustable widths and thicknesses. Its integrated vibration system enhances compaction, while its robust construction ensures durability and efficiency, significantly boosting project productivity.

Q: What types of environments and conditions can this paving machine operate in?

A: The machine operates efficiently in temperatures from -10C to +50C and can handle slopes up to 5%. Its powder-coated surface and high-grade materials ensure resilience in demanding construction environments, suitable for varied on-site conditions.

Q: When is the best time to use this canal paving machine during a project?

A: It should be deployed after excavation and formwork are complete but before channel commissioning. Using it during the lining phase ensures optimal structural integrity and an even, precise finish for irrigation channels or liners.

Q: Where can the CANAL PAVING MACHINE be transported and set up?

A: Fitted with heavy-duty wheels and designed for site mobility, it can be easily transported to construction sites within India or exported internationally. Its moderate dimensions and robust frame allow straightforward installation on a wide range of site profiles.

Q: What is the general process of using this machine for concrete lining?

A: The process includes setting up the machine on the canal bed, adjusting width and thickness as per design, and using the integrated vibration and trowel systems to lay and finish concrete. Manual and semi-automatic controls facilitate smooth operation by 1-2 operators.

Q: What are the key benefits for operators and project managers?

A: Operators benefit from easy access maintenance points, low upkeep, and user-friendly controls. Project managers can expect high daily capacity (up to 500 cubic meters), precise lining, and enhanced safety through emergency stop switches and overload protection.
